2019 – 2022 Silverado/Sierra: Manual to Power (Passenger) Seat Retrofit Harness

Description

Convert manual adjust passenger seat to power adjust passenger seat. read more

Customer Reviews

Based on 11 reviews
100%
(11)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
D
Darnell Defroe
PLUG AND PLAY VERY EASY TO INSTALL

Harness was plug and play no issues

B
Brad Sluman
Silverado seat up grade

Your harness and video made my life so much easier . You guys rock !
Thank you so much !
Brad

K
Kyle Hand
2022 Silverado 2500 HD Custom Trim Package

This is another great product from Harness Dr. Being as I have the custom trim level, my install was a bit different from the video provided.

First, the driver seat 12V lumbar power was already in the truck landed in the section suggested in the passenger fuse panel. I pulled that one out of that spot and installed the main pink wire from the harness in its place. Then I installed the original driver side 12V power into the additional pink wire (spade connector) that was provided on the passenger seat harness. This was intended for the drivers harness which I did not need to add.

Second, the right side buss (drivers fuse panel) on the custom trim was not hot. The right side buss was hot, so I connected to F3 since it was another spare slot.

J
Joey Wilson
Power passenger seat upgrade

Harness works great. Made the project quick and easy

M
Mathew Pullin

Good fit. Video was helpful. No issues!

Category:
Tag:
Weight:
.25 lbs
Dimensions:
9 × 6 × 1 in
view all details

Price

$74.99

Quantity

- +

Total

$74.99

0 reviews

- +

NEW

Description

Swapping out your manual adjust seats for power adjust seats on your 2019 – 2022 GMC Sierra or Chevy Silverado?  If you are missing the main power and lumbar circuits in your seat connector, this is the harness you’ll need.

Harness lands into OEM locations and will draw power from the OEM fused locations in your forward fuse panels. Harness will also include ground pin. If your truck has the ground pin (or the lumbar pin) then safely tape these back.

Installation Video – https://youtu.be/cngm0mjDLDs

NOTE:  If you are installing Denali/SLT, High Country/LTZ Seats in, you’ll like need an additional harness for the Driver Seat to bypass the seat memory module.

https://harnessdr.com/product/2019-2022-silverado-sierra-seat-memory-bypass-harness/

Product Compatibility:

Fits:

2019 – 2022: 1500 Silverado/Sierra Trucks

2020 – 2023: 2500HD, 3500HD Silverado/Sierra Trucks

Does Not Fit:

2019 LD (carry over 2018 K2XX): Silverado/Sierra Trucks

2022.5 “Refresh” – 2023+: 1500 Silverado/Sierra Trucks

2024+: 2500/3500 Silverado/Sierra Trucks

Additional information

Weight
.25 lbs
Dimensions
9 × 6 × 1 in
